Customized semiautomatic toroidal coil winding machine

The customized semiautomatic toroidal coil winding machine (SS200) is used for winding the thick wire on the toroid core. it adopts nylon hook to wind the enamel wire. it also be called three phase EMC filter winding machine, toroid EMI filter winding machine.

  • Item NO.:

    SS200
  • Product Orgin:

    China
  • Brand:

    SanShine
  • Shipping Port:

    XIAMEN,CHINA
  • Color:

    White and black
contact now
Description

Product name: Customized semiautomatic toroidal coil winding machine (SS200)

differential mode choke winding machine

EMC toroid filter winding machine

Description :

The Hook type customized semiautomatic toroidal coil winding machine (SS200) is one simply semiautomatic winder. It adopts the strong nylon hook to wind the enamel wire. It be designed and made according to user's Max. wire diameter and Max. dimensions of finished toroidal coil. So that user can change the winding jigs(module) only when they want wind the small size toroid coils. The winding machine (SS200) is used for winding toroid coils of the very thick wire and very heavy wire with big toroid core of coil and can wind many pieces wires in parallel at same time on the toroid core. Like as some big power toroidal factor corrector inductor, toroid power inductors, UPS toroidal inductor, heavy wire toroid choke coils. The winding machine (SS200) also be named thick wire common mode power line winder, thick wire toroid common mode inductor winding machine, toroid voltage fall transformer winding machine. The toroid coil winding machine (SS200) can protect the wire insulation film in good.

Features :

1. Easy to operate.

2. Need cut the required wire length before winding.

3. Easy to change the winding fixture for different size core.

4. Operation with compressed air.

5. Spread wire by manual.

Specification :

Wire diameter : 0.3 ~ 5.0mm (can wind many pieces wires in parallel at same time).

Min. finished coil inside diameter : 8mm (Will be different by hook size).

Finished coil outside diameter : 25~300mm(The SS200 winder is customized by toroid coil of dimensions and wire diameter.)

Winding type : By Hook with the air compressor.

Air source : 0.7Mpa .

How to select the best suited automatic toroid coil winding machine for your toroid coil?

Tell us the data of your toroidal coil as below please :

1. toroid coil outside diameter after winding?

2. toroid coil inside diameter after winding?

3. toroid coil height after winding?

4. the copper wire diameter ?

Request a free quote

Can't find the specific information you're looking for? Have a question ? Contact Us

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Related Products
  • heavy toroid winding machine Porogramable automatic extra heavy toroidal coil winding machine

    The porogramable automatic extra heavy toroidal coil winding machine (SS1001) is a very large scale winding machine. it adopts the large winding head with the large and strong winding shuttle. The winding machine is used for winding the large scale toroid coils. This winding machine(SS1001) can wind the outside diameter 800mm toroid coils with wire1

  • extra toroid transformer winding machine Automatic extra toroid double heads winding taping machine

    The automatic extra toroid double heads winding taping machine (SS-1000WT) adopts one big winding head and one tape big wrapping head to wind the large big toroidal coils with the thick enamel wire and wrap the insulation tape at same time. so it be also named doubel coil winding taping head machine.

  • fine wire small toroid winding machine Programmable slider type automatic toroid coil winding machine

    The programmable slider type automatic toroid coil winding machine (SS900S4) is used for winding the fine wire coils on the small toroidal core. like as small toroid transformers, toroid inductors and so on. This winding machine is named toroid current sensing transformer winding machine also.

  • toroidal coil winder Gear type automatic big toroid coil winding machine

    The gear type automatic big toroid coil winding machine (SS300 series) are used for winding the thick enamel wires on the big toroid core. Wind the big toroidal transformers, big toroidal voltage regulator coils, big toroid factor corrector coils. They are also called heavy wire toroidal coil winding machine.

  • fine wire toroid winder Slider type automatic big toroid coil winding machine

    The slider type automatic big toroid coil winding machine (SS300S series) is used for winding the fine wire big toroid coils. Like as: big toroid transformers, big toroidal inductors, big toroid current transformers, etc. . They also be named medium voltage instrument transformers winding machine, big toroid current sensor coil winding machine.

  • toroid winder Programmable belt type automatic toroid coil winding machine

    The programmable belt type automatic toroid coil winding machine (SS900B6, 6 inch winding head) is used for winding the thick enamelled wire on the toroid core. Also be named toroid common mode power line winding machine.

  • china toroid winding machine Programable automatic super big toroidal coil winding machine

    The programable automatic super big toroidal coil winding machine (SS1000) is a gear type toroid coil winding machine. this winding machine adopts the supper big winding head with strong winding shuttle. this toroid winding machine is used for winding the supper big toroid coils with the heavy wire. its winding capacity is finished coil Max. outsid1

  • toroidal passive inductor coil winding machine Belt type big automatic toroid coil winding machine

    The belt type big automatic toroid coil winding machine (SS900B8, 8 inch winding head) is used for winding the heavy wire coils on the big toroidal core. like as big toroidal transformers, big toroidal inductors and big toroidal filter coil etc.. Also it is a shuttle type toroid winding machine, a rectangular common mode coil winding machine which 1
