8inch slider type automatic toroid coil winding machine

The 8inch slider type automatic toroid coil winding machine (SS900S8, 8 inch winding head) is used for winding the fine wire coils on the big toroidal core. like as big toroid transformers, big toroid inductors and so on. This big toroid coil winding machine is named toroid sensor coil winding machine also.
  • Item NO.:

    SS900S8
  • Product Orgin:

    China
  • Brand:

    SanShine
  • Shipping Port:

    XIAMEN,CHINA
  • Color:

    Gray
contact now
Description

Product name : 8inch slider type automatic toroid coil winding machine (SS900S8)



toroid current transformer coil winding machine

toroid zero phase current coil winding machine

toroid zero phase transformer coil winding machine

fine wire toroid coil winder

Description :

The 8inch slider type automatic toroid coil winding machine (SS900S8, 8 inch winding head) is used for winding fine enamelled wire big toroidal coils. The 8inch slider type automatic toroid coil winding machine (SS900S8) adopts programmable precise CNC toroid controller, Adopts winding shuttle with slider. Shuttle and slider take the fine enamelled wire to wind on the big toroidal core in orderly by user's requirements. The 8inch slider type automatic toroid coil winding machine (SS900S8) is an accurately and reliability programmable accuracy toroidal winding machine. The SS900S series toroidal coil winding machine include : SS900S4 (4 Inch winding head), SS900S6 ( 6 Inch winding head), SS900S8 (8 Inch winding head). The 8inch slider type automatic toroid coil winding machine (SS900S8) is used for winding big toroidal inductor, big toroidal transformer, big toroidal current transformer, big toroidal current sensor, big toroidal coil, big toroid chock coil, big toroidal power magnetics, big toroidal converter inductors, watt metter current big toroidal sensors, etc. . The 8inch slider type automatic toroid coil winding machine (SS900S8) is called high frequency toroid booster winding machine and toroidal watt hour current transformer winding machine also.

Features :

1. Collocate slider type winding head,interchangeable roller table with different size shuttle(magazine) for different toroid coil demensions, wire diameter, turns, so that to reduce the cost. one set standard automatic toroid coil winding machne include one piece winding shuttle only, other sizes winding shuttles are optional.

2. Hi-tech shuttle for highest efficiency.

3. Separate speed controls for wire loading and winding.

4. Accurately count length of loading wire by length sensor, the wire length sensor be integrated in the winding motor.

5. Accurately count turns of winding by high frequency response photo-electricity sensor.

6. Programmable winding direction, winding returns range (turns or angle) and segment winding angle.

7. Accurately wire spacing by programmable controller.

8. Memory capacity accommodates 999 sequences of parameters with off-power memory retention.

Specification :

Copper wire diameter: 0.05 ~0.6 mm (will be different by different model, different shuttle size and coil height. )

Min. Finished ID: 4.5 mm (will be different by different model, different shuttle size, wire diameter, turns, core size, and coil height. )

Finished OD range: 5~150 mm (will be different by different model, different shuttle size and coil height. )

Max. Speed: 1800RPM

Winding motor: 1/2HP DC brushless motor

Spread motor: Stepping motor

Memory capacity: 999 steps

Power source: AC220V /110V +10%, 50/60 Hz

Dimension: L60x36x64(cm)

Net weight: 40 ~ 42 Kgs.

Model

Universally matched shuttle model

Copper wire diameter range(mm)

Min. inside diameter of finished coil (mm)

Out side diameter of finished coil range (mm)

Height of finished coil range (mm)

SS900S4

2.6 3.0 3.5 or customized

0.05 ~0.3

4.5

5 ~60

3 ~25

SS900S6

3.5 5.0 6.3 or customized

0.08 ~0.35

7

10 ~80

5 ~45

SS900S8

8 10 12 15 or customized

0.3 ~0.6

15

20 ~150

8 ~80


How to select the best suited automatic toroid coil winding machine for your toroid coil?

Tell us your toroidal coil of data as below please:

1. toroid core outside diameter before winding?

2. toroid core inside diameter before winding?

3. toroid core height before winding?

4. how many windings on this core?

5. how many turns of each winding?

6. how about the copper wire diameter of each winding?

7. provide pictures of product which is better.

Request a free quote

Can't find the specific information you're looking for? Have a question ? Contact Us

If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Related Products
  • heavy toroid winding machine Porogramable automatic extra heavy toroidal coil winding machine

    The porogramable automatic extra heavy toroidal coil winding machine (SS1001) is a very large scale winding machine. it adopts the large winding head with the large and strong winding shuttle. The winding machine is used for winding the large scale toroid coils. This winding machine(SS1001) can wind the outside diameter 800mm toroid coils with wire1

  • extra toroid transformer winding machine Automatic extra toroid double heads winding taping machine

    The automatic extra toroid double heads winding taping machine (SS-1000WT) adopts one big winding head and one tape big wrapping head to wind the large big toroidal coils with the thick enamel wire and wrap the insulation tape at same time. so it be also named doubel coil winding taping head machine.

  • Hook coil winding machine Customized semiautomatic toroidal coil winding machine

    The customized semiautomatic toroidal coil winding machine (SS200) is used for winding the thick wire on the toroid core. it adopts nylon hook to wind the enamel wire. it also be called three phase EMC filter winding machine, toroid EMI filter winding machine.

  • fine wire small toroid winding machine Programmable slider type automatic toroid coil winding machine

    The programmable slider type automatic toroid coil winding machine (SS900S4) is used for winding the fine wire coils on the small toroidal core. like as small toroid transformers, toroid inductors and so on. This winding machine is named toroid current sensing transformer winding machine also.

  • toroidal coil winder Gear type automatic big toroid coil winding machine

    The gear type automatic big toroid coil winding machine (SS300 series) are used for winding the thick enamel wires on the big toroid core. Wind the big toroidal transformers, big toroidal voltage regulator coils, big toroid factor corrector coils. They are also called heavy wire toroidal coil winding machine.

  • fine wire toroid winder Slider type automatic big toroid coil winding machine

    The slider type automatic big toroid coil winding machine (SS300S series) is used for winding the fine wire big toroid coils. Like as: big toroid transformers, big toroidal inductors, big toroid current transformers, etc. . They also be named medium voltage instrument transformers winding machine, big toroid current sensor coil winding machine.

  • toroid winder Programmable belt type automatic toroid coil winding machine

    The programmable belt type automatic toroid coil winding machine (SS900B6, 6 inch winding head) is used for winding the thick enamelled wire on the toroid core. Also be named toroid common mode power line winding machine.

  • toroid transformer tape taping machine Programable automatic big toroid core coil taping machine

    The automatic big toroid core coil taping machine (SS300T series) is used for winding the insulation tape or film on the toroid core and the toroid coil. This toroid core coil tape taping machine be named ferrite toroidal core tape taping machine and toroidal coil tape taping machine also.
